Environment: Indoor

Performance Level: Category 6

Cable Construction: U/UTP

Flammability Rating: LSZH

EuroClass Rating: Dca-s2,d2,a1

Copper Cable Flame Rating: LSZH – Dca

Resistance Properties: Flame-Retardant

Jacket Material: LSZH Material

Nominal Cable Outside Diameter (in.): 0.208

Nominal Cable Outside Diameter (mm): 5.2

Maximum Operating Temperature (°C): 60

Maximum Operating Temperature (°F): 140

Minimum Operating Temperature (°C): -20

Minimum Operating Temperature (°F): -4

Maximum Installation Temperature (°C): 50

Maximum Installation Temperature (°F): 122

Minimum Installation Temperature (°C): 0

Minimum Installation Temperature (°F): 32

Sub Brand: Pan-Net®

Maximum Installation Tension (N): 110

Maximum Installation Tension (lb): 25

Bend Radius (in.): 0.83

Bend Radius (mm): 21

Number of Pairs: 4

Conductor Material: Copper

Conductor Type: Solid

Overall Length (ft.): 1000

Overall Length (m): 305

Conductor Gauge: 24 AWG

Conductor Gauge (mm): 0.51

Insulation Material: High-Density Polyethylene

Insulation Diameter (in.): 0.037

Insulation Diameter (mm): 0.9

Maximum Voltage (V): 80

Standards Met:

Exceeds ISO 11801 Class E and ANSI/TIA-568.2-D Category 6, IEC 61156-5, IEC 60332-1, IEC 60332-3-22, IEC 60754, IEC 61034, EN 50575: Euroclass Dca-s2,d2,a1, meets IEEE 802.3af, IEEE 802.3at and IEEE 802.3bt for PoE applications, RoHS Compliant.

Color: Blue

Packaging Type: Carton

Product Type: Bulk Copper Cable
